motherboard chip
Integrated chip sound card/network card
Main chipset AMD A88X
Chipset description: Using AMD A88X chipset
Display chip CPU built-in display chip (requires CPU support)
Audio chip integrated Realtek ALC1150 8-channel sound chip
Network card chip Onboard Gigabit network card
Processor specifications
CPU type AMD A10/A8/A6/A4/Athlon
CPU Socket Socket FM2/FM2+
Memory specifications
Memory type 4×DDR3 DIMM
Maximum memory capacity 64GB
Memory description supports dual-channel DDR3 2600+(OC)/2400(OC)/2133/1866/1600/1333/1066MHz memory
storage expansion
PCI-E standard PCI-E 3.0
PCI-E slot 2×PCI-E X16 graphics card slot
1×PCI-E X1 slot
PCI slot 3×PCI slot
Storage interface 8×SATA III interface
I/O interface
USB interface 6×USB3.0 interfaces (2 built-in + 4 backplanes); 9×USB2.0 interfaces (6 built-in + 3 backplanes)
Video interface: 1×DVI interface, 1×VGA interface, 1×HDMI interface
Power interface: one 8-pin, one 24-pin power interface
Other interfaces: 1×RJ45 network interface, 1×optical fiber interface, audio interface, PS/2 keyboard and mouse universal interface, COM interface
Plate type
Motherboard form factor ATX form factor
