Motherboard chip
Integrated chip sound card/network card
Main Chipset Intel C224
Chip maker Intel
Chipset Description Using Intel C224 Chipset
Graphics chip Aspeed AST2300 + 32MB VRAM
Network chip Onboard Intel I210AT Gigabit LAN
CPU Specifications
Applicable platform Intel
CPU type Pentium/Celeron/Core i3/Xeon E3-1200 v3
CPU description Support Intel 22nm processor
CPU socket Socket 1150
Number of CPUs supported 1
Memory Specifications
Memory type DDR3
Memory Description 4×DDR3 DIMMs
Maximum support 32GB memory, support dual-channel DDR3 1600/1333MHz memory
Expansion slot
Graphics card slot 1×PCI-E X16 graphics card slot
1×PCI-E X8 graphics card slot
2×PCI-E X1 slot
PCI slot 2×PCI
SATA interface 4 x SATA III interface; 2 x SATA II interface
I/O interface
USB interface 4×USB2.0 interface; 4×USB3.0 interface
PS/2 interface PS/2 keyboard and mouse general interface
External port 1×VGA interface
4×RJ45 network interface
1×Fiber interface
plate type
Motherboard form factor ATX
Dimensions 30.48×24.4cm
