ASUS P9D-MX Used Sever Motherboard 1150 CPU Socket Intel C222 Chipset With Onboard Dual Intel I210AT Gigabit Network Card DDR3
Main chipset: Intel C222
CPU Socket: Socket 1150
Video card slot: 1 x PCI-E X16 video card slot 3.... >>
SATA interface: 4 x SATA III interface; 2×SATA.... >>
Detailed parameter
Motherboard chip
Integrated chip sound card/network card
Main chipset Intel C222
Chip manufacturer Intel
Chipset Description The Intel C222 chipset is used
Graphics chip Aspeed AST1300 + 64MB VRAM
Network chip onboard dual Intel I210AT Gigabit network adapter
CPU specification
Applicable platform Intel
CPU Type Pentium/Celeron /Core i3/Xeon E3-1200 v3
CPU Description Intel 22nm processors are supported
CPU Socket Socket 1150
Number of cpus supported 1
Memory specification
Memory type DDR3
Memory Description 4 x DDR3 DIMMs
Supports a maximum of 32GB memory and dual-channel DDR3 memory of 1600mhz and 1333MHz
Expansion slot
Video card slot 1 x PCI-E X16 video card slot
3 x PCI-E X8 graphics card slot
SATA ports 4 x SATA III ports; 2 x SATA II ports
I/O interface
USB port 2 x USB2.0 port; 2 x USB3.0 port
PS/2 ports Common ports for PS/2 keys and mice
External port 1 x VGA port
2 x RJ45 network port
1 x Optical fiber port
Plate cut
Main board type UATX board type
Overall dimensions 24.4×24.4cm
Other features
Other performance Raid 0, 1, 5, and 10 are supported
Other parameters
The hardware monitors the CPU temperature
Fan speed
One 8-pin power socket, one 24-pin power socket
