Motherboard chip
Integrated chip Sound card/network card
Main chipset Intel H81
Chipset description Using Intel H81 chipset
Display chip None
Audio chip Integrated Realtek ALC662 6-channel sound chip
Network card chip Onboard Realtek RTL8111G Gigabit network card
Processor specifications
CPU type Core i7/i5/i3/Xeon/Pentium/Celeron
CPU slot LGA 1150
CPU description Support Intel 22nm processor
Memory specifications
Memory type 2×DDR3 DIMM
Maximum memory capacity 16GB
Memory description Support dual-channel DDR3 1600/1333/1066MHz memory
Storage expansion
PCI-E standard PCI-E 2.0
PCI-E slot 1×PCI-E X16 graphics card slot, 2×PCI-E X1 slot
PCI slot 3×PCI slot
Storage interface 2×SATA III interface, 2×SATA II interface
I/O interface
USB interface 4×USB3.0 interface (2 built-in + 2 backplane), 8×USB2.0 interface (4 built-in + 4 backplane)
Power interface one 8-pin, one 24-pin power interface
Other interfaces 1×RJ45 network interface, 1×coaxial output interface, audio interface, PS/2 mouse, PS/2 keyboard interface
Board type
