Graphics chip Aspeed AST1300 + 64MB VRAM
Network chip onboard Intel I210AT gigabit network card
Expansion slot, Graphics slot :
1×PCI-E X16 graphics slot
1×PCI-E X8 graphics slot
4 × PCI graphics slot
SATA interface 2×SATA III interface; 4×SATA II interface
I/O interface
USB interface 4×USB2.0 interface; 2×USB3.0 interface
PS/2 interface PS/2 keyboard and mouse universal interface
Parallel serial port COM interface
External port 1×VGA interface
2×RJ45 network interface
Motherboard chip
Integrated chip sound card/network card
Main chipset Intel C222
Chip manufacturer Intel
Chipset description uses Intel C222 chipset
Graphics chip Aspeed AST1300 + 64MB VRAM
Network chip onboard Intel I210AT gigabit network card
CPU specifications
Applicable platform Intel
CPU type: Pentium/Celeron/Core i3/Xeon E3-1200 v3
CPU description Support Intel 22nm processor
CPU socket Socket 1150
Number of CPUs supported 1
Memory specifications
Memory type DDR3
Memory description 4×DDR3 DIMM
Maximum support 32GB memory, support dual-channel DDR3 1600/1333MHz memory
Expansion slot
Graphics slot 1×PCI-E X16 graphics slot
1×PCI-E X8 graphics slot
PCI slot 4 × PCI graphics slot
SATA interface 2×SATA III interface; 4×SATA II interface
I/O interface
USB interface 4×USB2.0 interface; 2×USB3.0 interface
PS/2 interface PS/2 keyboard and mouse universal interface
Parallel serial port COM interface
External port 1×VGA interface
2×RJ45 network interface
Board type
Motherboard board type ATX board type
Dimensions 30.5×24.4cm
