Motherboard chip
Integrated chip sound card/network card
Main chipset Intel Z170
Chipset description Using Intel Z170 chipset
Display chip CPU built-in display chip (requires CPU support)
Audio chip Integrated SupremeFX 6-channel audio chip
Network card chip onboard Intel I219V Gigabit network card
Processor specifications
CPU type Sixth generation Core i7/i5/i3/Pentium/Celeron
CPU socket LGA 1151
CPU description Support Intel 14nm processor
Memory specifications
Memory type 2×DDR4 DIMM
Maximum memory capacity 32GB
Memory description Support dual channel DDR4 4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/3500(OC)/3466(OC)/3400(OC) /3333(OC)/3300(OC)/3200(OC)/3000(OC)/2800(OC)/2666(OC)/2400(OC)/2133MHz memory
Storage expansion
PCI-E standard PCI-E 3.0
PCI-E slot 1×PCI-E X16 graphics slot
Storage interface 1×U.2 interface, 4×SATA III interface
I/O interface
USB interface 1×USB3.1 Type-C interface (backplane), 1×USB3.1 Type-A interface (backplane), 6×USB3.0 interface (2 built-in +4 backplane)
Video interface 1 × HDMI interface
Power interface One 8-pin, one 24-pin power interface
Other interfaces 1×RJ45 network interface, 1×optical interface, audio interface
Board type
Motherboard board type Mini-ITX board type
Dimensions 17.0×17.0cm
