Motherboard chip
Integrated chip sound card/network card
Main chipset Intel Z390
Chipset description Using Intel Z390 chipset
Display chip CPU built-in display chip (requires CPU support)
Audio chip integrated dual Realtek ALC892 7.1 channel audio chip
Network card chip Onboard Intel I219-V Gigabit network card
Processor specifications
CPU type 9th/eighth generation Core i9/i7/i5/i3/Pentium/Celeron
CPU socket LGA 1151
Memory specifications
Memory type 4×DDR4 DIMM
Maximum memory capacity 128GB
Memory description Support dual-channel DDR4 4400MHz memory
Storage expansion
PCI-E standard PCI-E 3.0
PCI-E slot 2×PCI-E X16 graphics slot, 1×PCI-E X1 slot
Storage interface 3×M.2 interface, 4×SATA III interface
I/O interface
USB interface 3×USB3.1 Gen2 interface, 2×USB3.1 Gen1 interface, 8×USB2.0 interface
Video interface 1×DVI interface, 1×Display Port interface, 1×HDMI interface
Power connector One 8-pin, one 24-pin power connector
Other interfaces 1×RJ45 network interface, 5×audio interface, 1×optical interface
Plate type
Motherboard type Micro ATX type
Dimensions 24.4×24.4cm
Other parameters
Multi-graphics technology support 2-Way AMD CrossFire technology
RAID function Support RAID 0, 1, 5, 10
Listing date October 2018
