Motherboard chip
Integrated chip sound card/network card
Main chipset Intel Z68
Chipset description Using Intel Z68 chipset
Audio chip integrated 6-channel audio chip
Network card chip Onboard Realtek RTL8111E Gigabit network card
Processor specifications
CPU type Core i7/Core i5/Core i3/Pentium/Celeron
CPU socket LGA 1155
CPU description Support Intel 32nm processor
Memory specifications
Memory type 4×DDR3 DIMM
Maximum memory capacity 32GB
Memory description Support dual-channel DDR3 2133/1866/1600/1333/1066MHz memory
Storage expansion
PCI-E standard PCI-E 3.0 standard
PCI-E slot 2×PCI-E X16 graphics card slot, 2×PCI-E X1 slot
PCI slot 2 × PCI slot
Storage interface 4×SATA II interface; 2×SATA III interface
I/O interface
USB interface 12×USB2.0 interface (6 built-in +6 backplane)
Video interface 1 × HDMI interface
Power connector One 4-pin, one 24-pin power connector
Other interfaces 1×RJ45 network interface, 1×optical interface, audio interface, PS/2 keyboard and mouse universal interface
Plate type
Motherboard board type ATX board type
Dimensions 30.5×21.5cm
Software management
BIOS performance 2 32Mbit flash
Use authorized AWARD BIOS
Support DualBIOS
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Other parameters
Multi-graphics technology supports the formation of AMD CrossFire multi-graphics mode
Overclocking function Support free overclocking technology
RAID function Support RAID 0, 1, 5, 10
Hardware monitoring System voltage detection
CPU/system temperature detection
CPU/system/power fan speed detection
CPU over temperature warning
CPU/system/power fan failure warning
CPU/system smart fan control
Whether the CPU/system smart fan control function is supported depends on the different CPU/system cooling fans.
Other parameters support Microsoft Windows 7/Vista/XP operating system
