Description
Integrated chip sound card/network card
Main chipset Intel H270
Chipset description Using Intel H270 chipset
Display chip CPU built-in display chip (requires CPU support)
Audio chip integrated Realtek ALC887 8-channel audio chip
Network card chip onboard Intel I219V Gigabit network card
Processor specifications
CPU type 7th/sixth generation Core i7/i5/i3/Pentium/Celeron
CPU socket LGA 1151
CPU description Support Intel 14nm processor
Memory specifications
Memory type 4×DDR4 DIMM
Maximum memory capacity 64GB
Memory description Support dual-channel DDR4 2400/2133MHz memory
Storage expansion
PCI-E standard PCI-E 3.0
PCI-E slot 2×PCI-E X16 graphics slot, 3×PCI-E X1 slot
PCI slot 1 × PCI slot
Storage interface 2×M.2 interface, 6×SATA III interface
I/O interface
USB interface 1 × USB3.1 Type-A interface, 1 × USB3.1 Type-C interface, 8 × USB3.1 interface (4 built-in + 4 backplane), 6 × USB2.0 interface (4 built-in + 2 backplane )
Video interface 1×DVI interface, 1×VGA interface, 1×HDMI interface
Power connector One 8-pin, one 24-pin power connector
Other interfaces 1×RJ45 network interface, 1×optical interface, audio interface, 1×TPM interface, 1×PS/2 keyboard and mouse universal interface
Board type
Motherboard board type ATX board type
Dimensions 30.4×24.3cm
Other parameters
Multi-graphics technology supports AMD CrossFireX hybrid crossfire technology
RAID function Support RAID 0, 1, 5, 10
Listing date January 2017
