Description
Motherboard chip
Integrated chip sound card/network card
Main chipset Intel H81
Chipset description Using Intel H81 chipset
Display chip CPU built-in display chip (requires CPU support)
Audio chip integrated Realtek ALC887 8-channel audio chip
Network card chip Onboard Realtek RTL8111G Gigabit network card
Processor specifications
CPU type Core i7/i5/i3/Celeron/Pentium
CPU socket LGA 1150
CPU description Support Intel 22nm processor
Memory specifications
Memory type 2×DDR3 DIMM
Maximum memory capacity 16GB
Memory description Support dual-channel DDR3 1600/1333/1066MHz memory
Storage expansion
PCI-E standard PCI-E 2.0
PCI-E slot 1×PCI-E X16 graphics card slot, 1×PCI-E X1 slot
Storage interface 2×SATA III interface, 2×SATA II interface
I/O interface
USB interface 2×USB3.0 interface (backplane), 8×USB2.0 interface (4 built-in +4 backplane)
Video interface 1×VGA port, 1×HDMI port
Power connector One 4-pin, one 24-pin power connector
Other interfaces 1×RJ45 network interface, audio interface, 1×PS/2 mouse, 1×PS/2 keyboard interface
Plate type
Motherboard type Micro ATX type
