Description
Detailed parameters
| Motherboard chip | |
| Integrated chip | Sound/network card |
|---|---|
| Main chipset | Intel X99 |
| Chipset description | Powered by Intel X99 chipset |
| Display chip | CPU built-in display chip (requires CPU support) |
| Audio chip | Integrated ROG SupremeFX 8-channel audio chip |
| Network card chip | Onboard Intel I218V Gigabit network card, Intel I211-AT dual Gigabit network card |
| Processor specifications | |
| CPU type | Core i7 X-series |
|---|---|
| CPU socket | LGA 2011-V3 |
| CPU description | Support for Intel 14nm processors |
| Memory specifications | |
| Memory type | 8×DDR4 DIMM |
|---|---|
| Maximum memory capacity | 128GB |
| Memory description | Supports quad DDR4 3333(OC)/3300(OC)/3200(OC)/3000(OC)/2800(OC)/2666(OC)/2400(OC)/2133MHz memory |
| Storage expansion | |
| PCI-E standard | PCI-E 3.0 |
|---|---|
| PCI-E slots | 4× PCI-E X16 graphics card slots, 1× PCI-E X4 slots, 1× PCI-E X1 slots |
| Storage interfaces | 1× U.2 interface, 1× M.2 interface, 10×SATA III interface |
| I/O interface | |
| USB interface | 2× USB3.1 Type-A interface, 2×USB3.1 Type-C interface, 8×USB3.0 interface (4 built-in + 4 backplane), 6× USB2.0 interface (4 built-in +2 backplane) |
|---|---|
| Power connector | One 4-pin, one 8-pin, one 24-pin power connector |
| Other interfaces | 2× RJ45 network interface, 1×S/PDIF digital audio output interface, 3× Wi-Fi antenna interface, audio interface, 1×PS/2 keyboard and mouse universal interface |
| Form factor | |
| Motherboard form factor | E-ATX form factor |
|---|---|
| Form factor | 30.5×27.2cm |
| Software management | |
| BIOS performance | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 5.0, Multi-Chinese BIOS, asus ez Flash 3, CrashFree BIOS 3, F11 EZ Setup Wizard, F6 Qfan Control, F3 Favorites, Quick Notes, History, F12 Screenshots, and ASUS DRAM SPD (Serial Presence Detect) Memory information |
|---|---|
| Other parameters | |
| Multi-graphics technology | Support NVIDIA SLI two-way crossfire technology Support NVIDIA 3-Way SLI three-way crossfire technology Support NVIDIA 4-Way SLI four-way crossfire technology Support AMD CrossFireX hybrid crossfire technology Support AMD 3-Way CrossFireX three-way crossfire technology Supports AMD 4-Way CrossFireX quad crossfire technology |
|---|---|
| Power supply mode | 8+2 phase |
| RAID function | Supports RAID 0, 1, 5, 10 |
| Wireless capability | Wireless: Support 802.11 a/b/g/n/acWiFi standard, support 11ac wireless communication standard, can support up to 1300Mbps transmission speed, support 2.4/5GHz wireless dual band |
| Bluetooth | Supports Bluetooth 4.0 |
| Other features | HIFI is supported |
| Listing date | 2016-07 |
